Frazier Incline Conveyors - Elevate your Expectations

Frazier & Son’s new line of Incline Conveyors are designed for high-end food and packaging applications. These robust stainless steel/sanitary constructed conveyors are designed with innovative quick release fold-out side boards and belt lifters to raise the belt from the frame for quick wash down without tools.

  • Provides gentle and reliable materials handling
  • Horizontal, incline and Z-shape configurations available
  • Robust stainless steel and sanitary construction
  • Quick release fold-out side boards expose frame and components
  • Easy clean belt lifter system speeds cleaning



incline conveyor closed sides

The Easy Clean Lever System

Sides open and the levers lift the belt away from the rollers, side boards, and frame to expedite cleaning and washdown.




Features

Robust, Sanitary Construction

Frazier & Son conveyors are built to last, are virtually maintenance free and designed with features to help processors easily comply with the Food Safety Modernization Act (FSMA) sanitary standards.

Sanitary construction includes:

  • Heavy duty stainless steel framework
  • Food grade compliant material contact points
  • Elimination of tubing, hollows and harborage points
  • Minimization of fasteners
  • Continuously welded standoffs and seams
  • Kevlar ® reinforced Urethane belt


Easy Clean Design
Frazier & Son’s tool-less quick release fold-out side board and elegant lever system raises the belt for fast cleaning and facilitate wet-wash downs.

  • Belt guides, rollers and sideboards are made of FDA compliant acetal and are hinged to quickly access the belt and components
  • Quick-release tensioner and belt lifters provide easy accessibility to the underside of the belt and the carry-ways for cleaning
  • Belt lifters raise the belt off the frame
  • UHMW-PE  carry-ways lift out without tools
  • Belting has sealed edges to prevent contamination
  • Welded belt splicing available to create a seamless belt which is cleaner and stronger than mechanical splicing methods
  • Cantilevered frame configuration available to enable quick removal of an endless belt
  • Made for wash-down environments, the belting offers excellent chemical resistance to many of the cleaners and sanitizing agents used in the food industry
  • Saves labor and water compared to cleaning other conveyors


Variable Speed Conveyors
Controls are available in a stand alone NEMA 4X enclosure, or can be integrated into remote system controls



Belt Tracking
Monolithic, Food Grade Urethane belting is positively guided throughout the conveyor eliminating nuisance tracking issues

  • Belting has positive drive and dynamic guides to ensure reliable tracking
  • Continuous carry-way belt support maintains control of the belt motion, keeping the product where it belongs



Belt Options

  • Low temperature materials
  • Positive drive styles
  • Straight cleats
  • Scoop cleats with or without corrugated sidewalls
  • Guarding and enclosure options available
  • Clean-in-place configurations available equipped with spray nozzles and air knives
  • Drum-motor or gearmotor drive configurations available



Conveyor Accessories
As with all Frazier & Son conveyor systems, these incline conveyors can be integrated with vibratory feeders, hoppers, belt feeds, check weighers, etc
